MATERIAL:
FULL LIQUID POST HEAT-TREATMENT ON 4130 “M2“ CRMO
TOP BOLT:
6061-T6 ALLOY TOP BOLT, M24 THREAD
STEERER LENGTH:
170MM
OFFSET:
24MM or 15MM
DROPOUTS:
6.5 MM INVESTMENT CAST DROPOUT AND BLADE END, HEAT-TREATED 4130 CRMO, FOR 3/8'' (10MM) AXLES
SPECIAL FEATURES:
• TEAM DESIGNED STREET FORK
• FULLY CNC’D STEERER
• INTERNALLY AND EXTERNALLY BUTTED
• SHORT 24MM OFFSET OPTION FOR RESPONSIVE STREET GEOMETRY
• INTEGRATED CROWN RACE DESIGNED TO WORK WITH INTEGRATED HEADSETS WITH A 45° BEARING
• TAPERED TRIPLE BUTTED FORK BLADES
• INCLUDES LIFETIME GUARANTEE
WEIGHT:
FORK: 1022G (36.05OZ : 2.25LBS) TOP BOLT: 33G (1.12OZ : 0.07LBS)
